Facility being the type of message, such as a kernel or mail message. And level being a severity level of the message. So to determine the facility value of a syslog message we divide the priority value by 8. The remainder is the level value.

What are facilities in syslog?

The Facility value is a way of determining which process of the machine created the message. Since the Syslog protocol was originally written on BSD Unix, the Facilities reflect the names of UNIX processes and Daemons. Note: Items in yellow are the facility numbers available on the SMS.

What is local facility in syslog?

The facilities local0 to local7 are “custom” unused facilities that syslog provides for the user. If a developer create an application and wants to make it log to syslog, or if you want to redirect the output of anything to syslog (for example, Apache logs), you can choose to send it to any of the local# facilities.

What is local0 facility?

The Local0-local7 are syslog facility values, which as defined by RFC 5424 – section 6.2. 1, are used to calculate the priority of syslog messages. In clear terms, the facility level allows you to logically separate syslog messages, e.g write to separate files or forward them to separate destinations.

What is default syslog facility level?

The default syslog facility setting is local7.

What is a syslog facility CCNA?

Syslog is a standard for logging messages. By default it sends message via UDP port 514. When a level is set, messages from that level an higher are logged. Common syslog facilities are IP, OSPF protocol, SYS operating system, IP Security, Route Switch Processor and Interface.

What is log facility?

The logging facility is an identification of a syslog packet that allows a syslog deamon to send the syslog message to the correct log file. The file syslog.conf on a unix server designates which log files syslog messages with a certain facility are sent.

What is Cisco syslog facility?

Syslog is a logging mechanism in network devices (Cisco Network Equipments, Unix Servers, GNU/Linux Servers) used to collect system logs which contains critical information about the status, errors, warning, configuration logs etc., of the devices. General working of Syslog protocol is defined in RFC 3164.

What is BSD syslog?

A BSD-syslog message consists of the following parts: PRI – represents the Facility and Severity of the message. It’s a calculated value: Facility * 8 + Severity. HEADER – contains a timestamp and the hostname (without the domain name) or the IP address of the device.

What is local6 in syslog?

I think 6 in local6 refers to the severity level of Syslog messages. If you set local6, then severity level 6 (information) and more severe (0-6) will be sent as log. 05-16-2005 03:42 AM

What are the syslog facilities?

Since the Syslog protocol was originally written on BSD Unix, the Facilities reflect the names of UNIX processes and Daemons. List of available Facilities as per RFC5424: Note: Items in yellow are the facility numbers available on the SMS.

How do I see local7 and local6 messages in Linux?

So you might have a log on your server for local7 messages, and you might have a log on your server for local6 messages. You can see that local7 messages are being logged to /var/log/syslog_info and local 6 messages sent to /var/log/syslog_bluesocket.

What is locallocal0 through to local7?

Local0 through to Local7 are not used by UNIX and are traditionally used by networking equipment. Cisco routers for example use Local6 or Local7. Recommended practice is to use the Notice or Informational level for normal messages. Explanation of the severity Levels: Default SMS setting for Syslog Security option.
